      home > product > UHF RFID reader | writer > channel reader / writer > ZT-STU-922

  UHF Passive RFID Gate Reader / writer (Product model: ZT-STU-922)



Price

  UHF RFID 32 CHANNEL RFID Reader



  SPECIFICATION

Working frequency 902~928MHz or 865~868MHz
Support protocol ISO18000-6C(EPC C1 Gen2)
RF chip Impinj R2000
RF power 0dBm~30dBm(adjustable)
SDK provide SDK and C#,VC,Java development routines
Download Software Development Kit
Communication interface Wiegand26/34/42,RS232,RS485,RJ45,WIFI
Reading distance 3m(depends on antenna, tag and environment)
Storage capacity 256M flash memory
Real time clock real time clock after power off
Frequency method hopping or fixed
Input/output interface 2 way relay output, 2 way I/O input
Tag signal value RSSI value detection
Antenna gain 12dBi circular polarization
Working method beep
Power supply 12V/3A
Size 1500*600*90mm(base:600*405mm)
Net weight 25*2kg
Material Aluminum alloy
Working temperature  -40℃~+65℃
Storage temperature  -45℃~+95℃
