T5577 contactless IC card |
| |
|
| |
|
| |
|
| |
|
| |
T5557,T5567 is a contactless Read/Write identification IC for applications in 125KHz frequency range. The antenna and chip together form a transponder or tag. The on-chip 330-bit EEPROM (10 blocks, 33 bits each) can be read and written block-wise from a reader. Block 0 is reserved for setting the operation modes of the T5557/67 tag. Block 7 may contain password to prevent unauthorized writing. Data is transmitted from the IDIC using load modulation. |
|
| |
|
| |
Chip Parameters |
| |
Chip Type |
ATA5557/5567 |
Frequency |
125KHz |
Supplier |
Atmel |
Mode |
Read/Write |
Protocol |
|
Memory |
330 bit |
Operating Distance |
Up to 50mm (depending on antenna geometry) |
Anticollision |
no |
Applications |
High security access control systems, Time attendance systems, Prepayment application, Loyalty program, Mass transportation ticketing, Staff identification |
|
| |
|
| |
Card Parameters |
| |
Dimention |
85.6×54×0.8 mm |
Material |
PVC, PET, ABS, PC, PETG |
Surface |
Matt / Glossy / Frosted |
Temperature |
-25~50 ‘C |
Weight |
6 grams |
Package |
200 or 250 pcs/box, or on request |
|
| |
|
| |
 T5567 chip datasheet (560 KB) |
| |
|
| |
|
