MIFARE Ultralight contactless IC card |
| |
|
| |
|
| |
|
| |
NXP has developed the MIFARE® MF01CU1 to be used with proximity coupling devices according to ISO14443A, it can act as single trip tickets in public transportation networks, loyalty cards or day passes for events. They are the ideal replacement for conventional ticketing solutions such as paper tickets, magnetic stripe tickets or coins. |
|
MIFARE® Ultralight can be easily be integrated into existing schemes and even standard paper ticket vending equipment can be upgraded. In addition this solution for low cost tickets can help operators to reduce fraud and the circulation of cash within the system. |
| |
|
| |
Chip Parameters |
| |
Chip Type |
MIFARE MF01CU1 |
Frequency |
13.56MHz |
Supplier |
NXP |
Mode |
Read/Write |
Protocol |
ISO14443A |
Memory |
512 bit |
Operating Distance |
Up to 100mm (depending on antenna geometry) |
Anticollision |
yes |
Applications |
Limited use tickets in public transport Limited use tickets in event ticketing |
|
| |
|
| |
Card Parameters |
| |
Dimention |
85.6×54×0.8 mm |
Material |
PVC, PET, ABS, PC, PETG |
Surface |
Matt / Glossy / Frosted |
Temperature |
-25~50 ‘C |
Weight |
6 grams |
Package |
200 or 250 pcs/box, or on request |
|
| |
|
| |
 MIFARE Ultralight chip datasheet (356 KB) |
| |
|
|
